Balluff Inductive standard sensor, PNP, NO, M8, flush, M8 3-pin Part number BES034Y

This inductive sensor detects metal targets at a rated operating distance of 1.5mm and provides a PNP normally open output for switching signals into a PLC or control input. The M8x1 stainless steel housing with flush mounting allows installation in confined spaces where the sensor face sits level with the surrounding mounting surface, and the IP67 rating supports use in washdown or contaminated industrial environments. It operates from 10 to 30 VDC and is supplied with a 300mm PUR cable terminated in an M8, 3-pin male connector for direct connection to field wiring.

Key specifications

• IP rating: IP67
• Operating voltage: 10 - 30 VDC
• Rated voltage: 24 V
• Connection: M8x1 / Male / 3-pin
• Output: PNP normally open (NO)
• Mounting: Flush mounting
